CAGRI 404
| Model | CAGRI 404 | ||
| Type | Four wheel drive | ||
| Overall Dimensions (L×W×H) (mm) | 3558×1690×1726 | ||
| Wheel base (mm) | 1910 | ||
| Wheel tread | Front (mm) | 1350 (Normal 1350), 1462 | |
| Rear (mm) | 1350～1650 ( Normal 1350) | ||
| Ground clearance (mm) | 390 | ||
| Min. turning radius (without one-side braking) | 4.3 | ||
| Tyres (Front/Rear) | 8.3-20/12.4-28 | ||
| Structural weight (kg) | 1925 | ||
|
Engine |
Model | ST3105BT or 3100A | |
| Type | Vertical, water cooled, four stroke, direct injection or ball firebox | ||
| Power/speed (kw/r/min) | 29.4 or 31 / 2200 | ||
| Fuel consumption (g/kw.h) | ≤ 248 or 254 | ||
| Rated traction (KN) | 12 | ||
| Gears | 8+2 | ||
| Speed scopes (km/h) | 2.39－31.58 | ||
| Max lifting forces (KN) | 7.6 | ||
| PTO | 634/2200rpm, 540/1872rpm | ||
