Cotton Picker
Jiangsu Wallong-Hsin Machinery Engineering Corp. Ltd. is a state-owned company, we are subsidiary of China National Machinery Industry Corporation (SINOMACH), under the management of Chinese Academy of Agricultural Mechanization Sciences (CAAMS). We have specialized in agricultural machinery for more than 20 years.
We have professional engineer team and experienced pre-sale and after-sale technicians. Our products has helped thousands farmers all over the world.
4CAM-3 is new generation of cotton picker with the characteristics, the features are as follows:
1. It is suitable for cotton picking operations in high-yield cotton fields and large, medium and small cotton fields, etc., with strong flexibility
2. Equipped with a Cummins engine with a rated power of 180 horsepower
3. It has a cotton picking head that can be equipped with 16 bars and 12 bars.
4. The powerful fan can ensure that the machine can reach the ideal picking speed when working in the high-yield cotton field, and improve the operation efficiency
5. Equipped with an automatic transmission gearbox, stepless speed change, easy and comfortable operation, more convenient in speed control for cotton fields with different yield.
6. The self-developed spindle picking has slight damage to the cotton fiber, operates with the agility and delicacy of a human hand:
| Description | Unit | Specification | |
| Whole Vehicle | Model | / | 4CAM-3 |
| External Dimensions (L×W×H) | mm | 8690×3450×4050 | |
| Steering Axle Track | mm | 2280 | |
| Weight | kg | 13000 | |
| Unloading Height of The Hopper | m | 1870~3870 | |
| Engine | Model | / | QSB5.9-C210-30 |
| Engine Type | / | 6 Cylinder, 4 Stroke, Supercharge, Air Cooling | |
| Compression Ratio | / | 17.3 | |
| Discharge | L | 5.9 | |
| Cylinder Diameter × Stroke | mm | 102×120 | |
| Reference Power | KW | 154 | |
| Rotating Speed | r/min | 2200 | |
| Gear-box | Model | / | NY1000/2-WX, Fluid Drive |
| Gears | / | 2 Gears | |
| Speed | First Gear For Cotton Picking | km/h | 0~7.5 |
| Second Gear For Walking | km/h | 0~25 | |
| Row Unit | Number Of The Spindle Bar in The Front Drum | / | 12 |
| Number Of The Spindle Bar in The Rear Drum | / | 12 | |
| Number Of The Spindles On Each Bar | / | 18 | |
| Number Of Spindles In Each Row | / | 432 | |
| Row Distance | Wide Row | mm | 914~1016 |
| Narrow Row | mm | 760~810 | |
| Cotton Hopper | Capacity | m3 | 25 |
| kg | 2650 (Seed Cotton) | ||
| Fuel Tank | Capacity | L | 380 |
| Fuel Type | / | 0~-20 Diesel | |
